Configure an IPv4 Address in Linux Server

Overview

This guide provides step-by-step instructions on how to configure an IPv4 address on various Linux distributions.

Prerequisites

Access to a Linux server (physical or virtual).
Root or sudo privileges.
Basic understanding of Linux command line.

Step 1: Identify Network Interface Name

First, you need to identify the network interface you want to configure. Run the following command:

ip link show

This command lists all network interfaces. Look for the interface name (e.g., eth0, ens33, etc.).

Step 2: Configure the IPv4 Address

To configure a static IPv4 address, you need to edit the network configuration files. The location and syntax of these files may vary depending on the Linux distribution.

1. Ubuntu/Debian (using Netplan)

For Ubuntu 17.10 and later, configurations are managed via Netplan:

sudo nano /etc/netplan/01-netcfg.yaml

Add the following lines to configure the static IP:

network:
    version: 2
    renderer: networkd
    ethernets:
        :
            dhcp4: no
            addresses:
              - /24
            gateway4:
            nameservers:
                addresses:
                - 8.8.8.8
                - 8.8.4.4

Example:

network:
    version: 2
    renderer: networkd
    ethernets:
        ens33:
            dhcp4: no
            addresses:
              - 192.168.1.100/24
            gateway4: 192.168.1.1
            nameservers:
                addresses:
                - 8.8.8.8
                - 8.8.4.4

2. Ubuntu/Debian (using /etc/network/interfaces)

For older systems or to use the traditional method:

sudo nano /etc/network/interfaces

Add the following lines:

auto
iface  inet static
    address
    netmask
    gateway
    dns-nameservers

Example:

auto eth0
iface eth0 inet static
    address 192.168.1.100
    netmask 255.255.255.0
    gateway 192.168.1.1
    dns-nameservers 8.8.8.8 8.8.4.4

3. CentOS/RHEL/Fedora

Edit the configuration file for the specific network interface:

sudo nano /etc/sysconfig/network-scripts/ifcfg-

For Ubuntu/Debian (using /etc/network/interfaces)

sudo systemctl restart networking

For CentOS/RHEL/Fedora

sudo systemctl restart network

For Arch Linux

sudo systemctl restart systemd-networkd

Step 4: Verify the Configuration

Run the following command to verify your new IP address:

ip addr show

Check that the interface displays the new IP address you configured.

Summary

By following the steps in this guide, you will have successfully configured a static IPv4 address on your Linux server in various distributions. Always ensure your configuration is correct by verifying connectivity with tools like ping.

Note: Always back up configuration files before making changes and consult your network administrator if unsure about IP address assignments.
